NB: The height is changed to 2700mm
Features:
- Modern, clean design to fit all decor
- Resistant to all types of weather
- Impact resistant, eco-friendly, UV-resistant panels.
- Can be used as an additional room when walls/partitions are added
- Perfect for entertaining year-round
- German designed Bayer® 4mm PC polycarbonate panels
Specifications:
- Au Frame 6063-T5
- Aluminum Frame Color:Charcoal / White
- Roof panel Color: Light Grey
- PC Board: thickness 4mm
- Bavere PC polycarbonate panels
- 10-year warranty on polycarbonate roof sheets
- Wind Load: 110km/h
- Snow Load: 100kgs/m2
- Post: 110*110mm, thickness 2mm height 2.7m
- Front Beam: 160.2 x 129.29mm, thickness 2.5mm
- Back Beam: 139.13 x 45.81mm, thickness 2mm
- Side Beam: 109 x 50mm, thickness 1.5mm
- Middle Beam: 109 x 50mm, thickness 1.5mm
- Support Profile: 91.96 x 14.69mm, thickness:2.5mm
- Package Material: Honeycomb Carton
- 10-year warranty on the aluminium frame
- 10-year warranty on polycarbonate roof sheets
Note:
Side quarter Window is not included. If you need it, please purchase it separately.
Package Contents:
- 1x Coastal Patio Cover
- 1x Instruction Manual
Click to download:installation manual
3 x 3m | 4 x 3m | 5 x 3m | 6 x 3m | |
Package 1 | 285 x 26.5 x 16cm, 22kg | 285 x 26.5 x 16cm, 22kg | 285 x 37.5 x 16cm, 30.7kg | 284.5 x 36 x 14cm, 41.84kg |
Package 2 | 305.5 x 21 x 19cm, 27kg | 210 x 22 x 25cm, 32.2kg | 286.5 x 22 x 25cm, 40.4kg | 314 x 19 x 22.5cm, 44.82kg |
Package 3 | 293 x 35.5 x 16cm, 36.4kg | 293 x 39.5 x 16cm, 42kg | 293.5 x 29.5 x 16cm, 26.1kg | 298 x 23 x 19.5cm, 32.97kg |
Package 4 | 290 x 56.8 x 5cm, 41.2kg | 229 x 63.6 x 5cm, 53kg | 293.5 x 29.5 x 16cm, 31kg | 298 x 23 x 14.5cm, 22.96kg |
Package 5 | 66 x 55 x 20cm, 11.94kg | 66 x 55 x 20cm, 13.64kg | 290 x 59.6 x 5cm, 60kg | 297 x 66.5 x 45cm, 63.95kg |
Package 6 | 66 x 55 x 20cm, 23.68kg | 66 x 55 x 20cm, 21.1kg | ||
3 x 4m | 4 x 4m | 5 x 4m | 6 x 4m | |
Package 1 | 284.5 x 25 x 14cm, 24.85kg | 284.5 x 25 x 14cm, 29.85kg | 285 x 37.5 x 16cm, 30.7kg | 285 x 37.5 x 16cm, 30.7kg |
Package 2 | 303 x 19 x 16cm, 22.98kg | 208.5 x 19 x 22.5cm, 29.91kg | 286.5 x 22 x 25cm, 40.4kg | 338 x 22 x 25cm, 48.5kg |
Package 3 | 398 x 23 x 19.5cm, 44.67kg | 398 x 28 x 19.5cm, 51.85kg | 396 x 29.5 x 16cm, 35kg | 396 x 29.5 x 16cm, 41.6kg |
Package 4 | 397 x 59.8 x 30cm, 42.49kg | 397 x 59.5 x 30cm, 56.48kg | 396 x 24.5 x 16cm, 41.3kg | 396 x 29.5 x 16cm, 41.6kg |
Package 5 | 66 x 55 x 20cm, 11.94kg | 66 x 55 x 20cm, 13.64kg | 390.9 x 59.6 x 5cm, 90kg | 390.9 x 63.6 x 5cm, 107kg |
Package 6 | 66 x 55 x 20cm, 21.1kg | 66 x 55 x 20cm, 27.7kg |
Polycarbonate Sheet Color:
Living Culture always aims to dispatch your item as soon as possible. Please note items will not be dispatched until payment has been received in full.
Estimated delivery times will be displayed at the time of checkout.
Click & Collect
At checkout, select Pickup as your shipping method. Our team will contact you once your goods are ready. Pickup is only available at our warehouse in Point England (near Panmure).
Shipping Costs
Use the shipping calculator by entering your postcode to get an estimate of the shipping cost.
Returns
We will provide a full refund (including shipping) if:
- The faulty item is found to be defective and we are unable to fix or replace it
- The item was incorrectly described in website listing
Learn more about our Return and Refund Policy
If you have any Questions or Concerns
-Live chat with us
-Call us on 0800 298 398
-Email us at support@livingculture.co.nz
-Visit Our Showroom: 139 Wairau Road, Wairau Valley, Auckland, 0627
At livingculture.co.nz, we want to offer you the best shopping experience possible. We're here to help you in any way possible!
Generally all products at Living Culture have at least a 12 month warranty. You can check the warranty information of each item in the product description. Contact us within the warranty period if you encounter any problems associated with the product.
Living Culture will replace your product if it is found to be “dead on arrival” (DOA) at our cost.
If you change your mind after the payment is confirmed, we will issue a store credit (lessany shipping and handling fees) and the item can be returned to us at your cost. Items must be returned in "as new" condition with all packaging and accessories (including manuals).
If your item is faulty, please contact us within the warrant period and we will assess your claim on a case-by-case basis and offer a replacement, full refund or store credit.
Seamless Indoor-Outdoor Living
Sleek Wall-Mounted Design
Designed for a smooth connection between your home and garden, it adds a touch of modern sophistication to any area.
Expansive Coverage
With a generous span, this patio cover is perfect for creating a spacious outdoor retreat, ideal for dining, entertaining, or simply relaxing.
What makes it special?
Choose Your Style
Need a unique size or colour? Contact us to customise your patio cover to fit your specific needs.
Viewing
Sizes
3 x 3m, 3 x 4m, 4 x 3m, 4 x 4m, 5 x 3m, 5 x 4m, 6 x 3m, 6 x 4m
3 x 3m, 4 x 3m,4 x 4m,5 x 3m, 5 x 4m, 6 x 4m
3 x 3m, 4 x 3m, 4 x 4m, 5 x 3m,5 x 4m, 6 x 4m
Frame Colours
White / Charcoal
White / Charcoal
White / Charcoal
Panel Colours
Light Grey
Light Grey
Light Grey
Polycarbonate Panel Thickness
4mm
2mm
2mm
Warranty
10 Years
10 Years
10 Years
